THERMTRACE® LongHeat

SERIES RESISTANCE HEATING TAPE

Properties of heating tape

• Long heating circuits up to 2km

• Moisture proof

• Flexible and solid

• Efficient and flat

• High temperature resistant

Technical data

Maximum exposure temperature (unpowered): 225°C

Nominal voltage: up to 450V

Min. bending radius: 25mm

Min. installation temperature: -50°C

Buswires: tinned copper

Applications

The ThermTrace LongHeat heating tape is a series

resistance heating tape designed for longer circuit

runs. TTLH can be connected in various ways to deliver multiple wattages and configurations.



Properties of heating tape

Name



Resistance Ω/m

TTLH-2-A  0.0185 Ω/m
TTLH-2-A  0.0185 Ω/m
TTLH-3-A  0.0185 Ω/m
TTLH-4-A  0.0185 Ω/m
TTLH-2-B  0.0123 Ω/m
TTLH-3-B  0.0123 Ω/m
TTLH-4-B  0.0123 Ω/m
TTLH-2-C  0.0074 Ω/m
TTLH-3-C  0.0074 Ω/m
TTLH-4-C  0.0074 Ω/m

Other wattages and voltages can be manufactured to order

TTLH 2

TWO BUSWIRES

Can be used on its own or in multiples on single or three phase electrical systems.

TTLH 3

THREE BUSWIRES

Can be used on its own or in multiples on single or three phase electrical systems.

TTLH 4

FOUR BUSWIRES

Can be used on three phase electrical systems in Multiple tapes configurations.
